DOLPHICAM 2+ MILITARY SPEC

This product is adapted specifically for use within the defence market; the internet connection and camera have been disabled. The pelicase contains a connected Black Box, rugged tablet, software and all cables and accessories that are needed for using the dolphicam2+ platform, including room for storing two transducer modules.

Download Brochure

Category:

Description

  • Pelicase
  • 14” DT340T tablet
  • Black Box
  • Black Box power supply with international adapters
  • Box with a screwdriver for USB-Cables
  • Test and practice material sample
  • Frame with kickstand

Technical Details

  • Black Box
  • PC/Host port USB C
  • Transducer ports 2x USB C
  • Encoder ports 2x GPIO
  • Other connections Ethernet
  • Tablet
  • Intel® 8th Generation Core™ I quad-core processor
  • Ingress protection IP65
  • Battery life: 6-8 hours (normal use)

Size And Weight

Dimensions:

  • Toughpad and Black Box: 300 x 188 x 70mm / 11.8 x 7.4 x 2.7”
  • Toughpad: 185 x 273 x 19mm / 7.2 x 10.74 x 0.7”
  • Pelicase: 560 x 360 x 230mm / 22 x 14.1 x 9”
  • Weight:
  • TRM + USB-C cable: 360g / 0.7lbs
  • Core Unit (Black Box + Toughpad): 2.6kg / 5.8lbs
  • System packed in custom pelicase (Working system + 2x charging cables + pelicase): 8.2kg / 18.0lbs”
